Why is the anchoring method so important?

I recently dismantled my neighbor's old fence - the posts had been standing for only 8 years and looked as if they had suffered an earthquake. One was tilted by 20 degrees, the other was literally lying on the ground. The reason? The posts are dug without concrete into heavy, clay soil, which freezes and swells in winter.

The four main methods - a quick overview

In practice, we use several basic methods depending on the type of soil, loads and durability for which we design.

Column feet poured with concrete - classic and reliable

• Depth: the frost line in Poland is 80-100 cm - the foundation must reach below this depth
• Hole diameter: minimum 2× post thickness - for a 60×60 mm post, opening approx. 150 mm
• Concrete: minimum B15, mix with aggregate up to 16 mm, not thin
• Wood: impregnate the lower end twice and varnish with bitumen
• Seasoning time: minimum 48 hours before loading, 7 days before mounting heavy elements

When to use: durable fences, sheds, pergolas, gate posts - wherever durability of 20+ years is important.

Screw-in (screw) anchors

• Soil: great in sand, forest, garden soil. Poorer in hard clay and stone
• Advantages: no concrete, assembly in an hour, easy disassembly
• Disadvantages: more expensive than concrete, less resistant to torques in strong winds
• Load capacity: the fi60 anchor withstands a tensile load of approx. 5-8 kN - check the technical data sheet

When to use: garden gazebos, temporary fences, roofs with lightweight structures.

Polumn feet (anchors) on concrete or masonry

• Metal feet screwed to the existing concrete surface
• For concrete: expansion plugs or chemical anchors - the latter are stronger
• The pole has no contact with the ground - it does not rot

When to use: terraces, balconies, concrete surfaces, sheds attached to the foundation.

Dry vs wet soil - it matters

• Sand and gravel: natural drainage, screw anchors are great, concrete requires side form
• Clay: freezes and swells - foundation below 80 cm, anchors hold weaker
• Peat and embankments: unstable soil - geotechnical design needed

It is always worth checking the ground with a shovel to a depth of 30-50 cm before installation. If there is water in the ground after rain, plan drainage or a deeper foundation.
